Marca: Transcension

Tienda: ESLDJ

Disponibilidad: En almacén, envío inmediato.

The Transcension 12 channel dimmer is a high quality installation DMX dimmer pack that supports 1 or 3 phase operation. Product features 1 or 3 phase selector, 12 channels, 20A per channel (Total MAX 240A), microchip control, 0-50% preheat for lamps, linear dimming, short circuit protection for each channel, LCD menu and power failure memory. Each channel can be easily removed for service without the inconvenience of disconnecting the complete dimmer rack, saving valuable time and money.12 channel modular digital dimmer packUSITT DMX-512 (3-pin) input4U 19" rack mountHigh speed micro processorReal time zero crossing detectionBacklit digital displayDimming response time down to 24mSMinimum channel output setting from 0-30%Maximum channel output setting from 70-100%Individual channel curve option settingChannel curve settings include Linear, Square, Non Dim and S-Curve.DMX fail backup featureProgrammes, last scene hold and analog optionsPower failure memory DMX OutputFan cooled12 x 20A UL approved MCB breakers.20A/CH. Total 240A single phase connection20A/CH. Total 80A per phase-three phase connectionLCD display for indication in dark environmentsRugged construction ensures long life, even under the most demanding conditionsChannel output: 20A via screw terminals on din rail Power supply: 240VDimensions: 482 x 370 x 175mmWeight: 18.3kgs
