Marca: Proxim

Tienda: CiudadWireless

Disponibilidad: En almacén, envío inmediato.

Tsunami.GX 90 5.8 GHz ISM System, High Band, A2 Channel - 67254 Proxim's Tsunami.GX is a full-duplex point-to-point wireless Ethernet bridge with an innovative split-box design. This latest generation of high-capacity wireless bridges is designed to reduce the expense of extending IP networks and to simplify installation. Secure wireless technology significantly reduces total cost of ownership and speeds deployment, while a split-box design adds installation flexibility. The Tsunami.GX also provides best-in-class system performance with native IP interfaces by eliminating the overhead associated with DS3-to-Ethernet connections. Perfect for data and data/voice network backhaul applications and for replacing, extending or backing up leased lines Indoor-only installation facilitates quick maintenance and easier upgrades Indoor/outdoor installation improves system gain and reduces total cost of ownership Easily manage and trouble-shoot your wireless network Tsunami.GX bridges offer sophisticated, preventative management tools to simplify network maintenance and eliminate downtime. Advanced diagnostic tools identify and isolate potential issues before they impact the network. Standards-based SNMP management and web-based GUI simplifies remote management and integrates easily into existing software platforms Built-in spectrum analyzer and an alarm log facilitate RF planning and post-deployment tuning The Cost of Ethernet at the Speed of DS-3 Backed by more than 20 years of wireless design innovation, Proxim's Tsunami wireless bridge family easily and affordably enables network extension, redundancy and backhaul. Tsunami wireless bridges eliminate fiber installation costs and leased line fees to bring you the capacity of DS-3 with the TCO of Ethernet. High capacity for bandwidth-intensive applications such as PBX extension, data backhaul and critical link redundancy No expensive recurring leased line costs Superior system gain ensures consistent, high quality network operation Deploy in daysa Because Tsunami bridges operate in license-exempt ISM frequency bands, they can be deployed quickly - eliminating the long lead times associated with leasing lines or trenching new fiberoptic cable. This is especially useful in network redundancy and contingency planning. Rapid device deployment and flexible re-deployment ISPs maintain business continuity, even in severe conditions Enterprises minimize costly business application downtime Reliable and Secure A wireless alternative to a wired network yields quality as well as flexibility. Proxim's Tsunami bridges offer the highest security and reliability available in networking today. Over 99.999% reliable RF transmission Meets or exceeds wired network security Proprietary encryption methods ensure secure data transmission Applications: Enterprise LAN and PBX extension WAN connection redundancy ISP remote POP ISP direct customer connections using point-to-point Multipoint backhaul at DS-3 performance Extension of an existing fiber network Frequency Digital Capacity Channel Pairs FCC Emmission Designator Threshold (BER=1x10 -6 ) Output Power System Gain Distance (Miles/KM) 5725-5850 MHz - 98 Mbps 4 1 28M1G7D ≤-80 dBm ≥+23.5 dBm 1 ≥103.5 dB, 106 dB typ. 0 to >33.7/54.4 3 System Configuration Split-box: IDU, RF Unit Modulation DSSS; QPSK Frequency Stability ±10 ppm RF Attenuation Range 1 ≥20 dB Maximum Receive Signal -20 dBm error free; 0 dBm no damage Error Floor 100000 hours >100000 hours Physical Dimensions IDU RF Unit Size (in/cm) 17.2 X 10.9 X 1.72 / 43.6 X 27.6 X 4.4 14.1 X 10.9 X 1.72 / 35.8 X 27.6 X 4.4 Weight (lbs/kg) 6.5/2.9 12.0/5.4 Mechanical RF Unit Antenna Port (outdoor RF cable not provided) Type-N female IDU Port TNC female Cable to IDU LMR-240 or equiv. <100m LMR-400 or equiv. <200m LMR-600 or equiv. <300m Mounting IDU EIA rackmount, 19” or 23”, 1RU RF Unit EIA rackmount, 19”or 23”, 1RU, or outdoor pole mount bracket (optional) Selectable Frequency Channel Pair Channel Plan A 5745/5830 MHz Ordering Information 67255 Low Band Terminal, 301-57710-61L0 67254 High Band Terminal, 301-57710-61H0 ACC-GX-RF-2 Optional RF Unit Outdoor Mounting Kit 201-31075-1 Optional AC Adapter 110/220 VAC with cable and connector Shipping Configuration Tsunami.GX 90 IDU (Indoor Unit) ISM Low Band or High Band Unit IDU Indoor Rack ACC-GX-RF-1 RF Unit Indoor Mounting Kit (includes 12” IDU to RFU TNC-to-TNC cable) Quick Install Guide CD-User Documentation 1 Output power is specified at zero attenuation 2 Does not include air latency of approximately 5.4 µsec/mile 3 RF Unit installed outdoors with 6ft. parabolic antenna, 99.995% one-way availability, average climate/terrain, no multipath reflection. 4 No Waysides enabled
