Marca: Crydom

Tienda: Farnell

Disponibilidad: En almacén, envío inmediato.

RELAY,SOLID STATE 20A 480V; Operating Voltage Min:48Vrms; Operating Voltage Max:530Vrms; Control Voltage DC Min:4VDC; Control Voltage DC Max:32VDC; Control Voltage AC Min:90VAC; Control Voltage AC Max:280VAC; Contact Configuration:SPST-NO; Load Current:20A; Switching Mode:Zero Crossing; Relay Terminals:Cage Clamp; SVHC:No SVHC (20-Jun-2013); Blocking voltage:1200V; Control Current Min:8mA; Control Current Typ:12mA; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; External Depth:99mm; External Length / Height:81.3mm; External Width:22.4mm; Input Voltage Max:530V; Input Voltage Min:48V; Leakage Current:10mA; Load Current Max:20A; Load Current Min:150mA; Load Current RMS Max:20A; Operating Voltage Range:48Vrms to 530Vrms; Output Type:SCR; Peak Surge Current:250A; RMS Load Current Min:0.15A; RMS Load Voltage Max:530V; RMS Load Voltage Min:48V; Rate of Voltage Change dv / dt:500V/s; Series:CKR480; Single Cycle Surge Current:250A; Surge Current:250A; Terminal Type:Box Clamp Type
